Built in 1998


SPECIFICATIONS

TYPE Ocean Going Tug
CLASS Bureau Veritas
DESIGN Robert Allan Ltd., Canada
LOA 18.29ms
BEAM 7.00ms
DEPTH 2.91ms
DRAFT 3.00ms
GROSS TONNAGE 73.77GT
NET TONNAGE 50.90
BRAKE HORSEPOWER 2,200BHP/1432kW
BOLLARD PULL 30Tbp
MAIN ENGINES 2 x 1100 BHP Caterpillar 3508 B DITA
Marine Engines 1,800 rpm
GEAR BOXES 2 x Reintjes WAF 561 reverse reduction
gearboxes Reduction ratio of 5.05:1
PROPULSION SYSTEM 2 x 1700mm Cu-Ni-Al Bronze propellers
in twin fixed 1930mm kort nozzles tail
shaft-main shaft/coupling and propeller
manufactured by "Lips" "Wartsila"
ENGINE CONTROL 2 x Rexroth Pneumatic Control System
RUDDERS/STEERING 2x2 x 45 degree Jastram high aspect
flap rudders ( x 2 for each nozzle )
powered by variable displacement
hydraulic pumps installed to the main-
engines' power take off. System is
completely "load sensing" and
independent of engine speed.
BODY Steel/Aluminium (accomodation)
TOWHOOK Mampaey DCX 18-25 disk type
Data Hydraulic CAPSTAN
Data Hydraulic ANCHOR WINCH
1,000 watt 24 v Norselight.
(*) 1,000 watt 24 v Seematz
FI-FI
2 x Sailor RT 2048 VHF (*) M127 ICOM Marine VHF VHF
1 x Koden 24 Mil Radar
(*) JMA 1100 JRC Color
LCD Radar 1800 Plotter Set
RADAR
